Description
Experience the convenience and hygiene of touch-free door access with the EB200 infrared door release button. Wave your hand to activate, and watch the bio-color LED indicators (blue for standby, green when triggered) guide your way. Ideal for offices, hospitals, schools, and homes, the EB200 ensures seamless integration with various locking systems. Customize it with your logo to match your space.
Key Features:
Stylish and aesthetic cover design
No touch/touch free infrared exit sensor
Bio-color backing light indicators: blue (door closed), green (door opened)
Momentary action switch, wave to open
Designed to Control Electric Locks/Strikes, Magnetic Locks, or Automatic Door
Weather proof design suitable for indoor and commercial use
Specifications
| Technology | Infrared sensor technology |
| LED Color | blue (Standby, door closed),green (Trigged, door opened) |
| Power Supply | 9V -15V DC |
| Current | <40mA |
| Maximum Sensing Range | 5 cm |
| Output | NC/NO/COM |
| Activation Time | 1-5 Second or as Long as Sensor is Triggered |
| Housing Material | ABS |
| Operating Temperature | -10℃ to +65℃ |
| Humidity | 0~95% relative humidity noncondensing |
| Dimension | 86mmx 86mm x 22 mm |
| Weight | 120 g |
Ordering information:
To order, please use exact Model Number
| Model Number | Indicator |
| EB200 | Blue and green |
Note: Your logo is customizable as per request and meet M.O.Q. Other requirements, please contact our sales (sales@bestonetec.com) directly.
Wire Definition
| Wire Color | Definition | Remarks |
| Red | VCC | Power + |
| Black | GND | Power – |
| Yellow | COM | Relay Com output |
| Orange | NC | Relay NC output |
| Brown | NO | Relay NO output |
Typical Application
Offices, library, hospitals, labs, schools, public and commercial places and home use, compatible with electric locks/strikes, magnetic locks, or automatic doors
